KM218
KM218 passive subwoofer cabinet is designed with a 2400 W, 18” woofer capable of 144 dB SPL, in a Birch Ply enclosure. Omni dispersion and frequency response of 37 Hz.
The rear cast aluminium connection plate has two 4 pin speakON® connectors fitted as standard, one input and one link. The speakON® connectors are wired on pins +1-1, with pass through of pins +2-2.
Key Features
Hi-Fi grade components give extended 37 Hz frequency response
Omni directional
4 Ohm impedance
Product Details
Design
Impedance
Power Handling (AES)
Max. Power Handling (AES)
Frequency Range (±3 dB)
Dispersion
Sensitivity 2.83V / 1m
Max. SPL
Double 18″ Subwoofer Cabinet, Reflex Tuning
4 Ohm,
2400 Watts (continuous)
3500 Watts (program)
7200 Watts (peak 10 ms)
37 Hz-90 Hz
Omni Directional
125 dB
138 dB cont
144 dB peak
Dimensions (H x W x D mm)
Weight (kg)
SYSTEM OPERATION
Recommended Amplification
System Controller
Speaker Cables
PRODUCT FEATURES
Components
Crossover
Connectors
Shipping Weight (kg)
Colour
Options
Rigging
HARDWARE
Fitted as Standard
Optional
Additional Descriptive Data
1158 x 580 x 920
106
Spacer Text
2400 – 3600 Watts
Ohm DSP Solutions
Min – 2 x 4 mm2
Preferred – 2 x 6 mm2
Spacer Text
2 x 18” low frequency driver
–
2 x 4 pole speakON® Connectors
108 (1 cabinets per carton)
Black
White or RAL colours on request. Weather resistant version available on request
–
Spacer Text
–
–
Birch Ply construction, with durable scratch resistant black textured paint finish, kick-proof steel grill and black foam with Ohm logo.
